Question

a scatter plot is shown.

choose the set of coordinates that would best be used to sketch a line of fit for the data.

• \\((3, 5)\\) and \\((8, 7)\\)
• \\((2, 3)\\) and \\((6, 6)\\)
• \\((1, 4)\\) and \\((9, 10)\\)
• \\((2, 2)\\) and \\((9, 10)\\)

Explanation:

Identify the trend of the scatter plot

The data points on the scatter plot are:

$$ (1, 4), (2, 2), (2, 6), (3, 5), (4, 3), (5, 5), (6, 7), (7, 6), (8, 10), (9, 9) $$

As \(x\) increases, \(y\) generally increases, showing a positive linear correlation.

Evaluate the given coordinate pairs

We test which pair of points forms a line that best represents this positive trend:

• \((3, 5)\) and \((8, 7)\): Slope \(m = \frac{7 - 5}{8 - 3} = 0.4\). This line is too flat and lies below most of the upper points.
• \((2, 3)\) and \((6, 6)\): Slope \(m = \frac{6 - 3}{6 - 2} = 0.75\). This line passes centrally through the data points.
• \((1, 4)\) and \((9, 10)\): Slope \(m = \frac{10 - 4}{9 - 1} = 0.75\). This line also passes centrally through the data points.
• \((2, 2)\) and \((9, 10)\): Slope \(m = \frac{10 - 2}{9 - 2} = 1.14\). This line is too steep.

Determine the best fit line

Comparing \((1, 4)\) and \((9, 10)\) with \((2, 3)\) and \((6, 6)\):
The line through \((1, 4)\) and \((9, 10)\) has the equation:

$$ y - 4 = 0.75(x - 1) \implies y = 0.75x + 3.25 $$

The line through \((2, 3)\) and \((6, 6)\) has the equation:

$$ y - 3 = 0.75(x - 2) \implies y = 0.75x + 1.5 $$

Let's calculate the sum of residuals for both lines to find the best fit:
For \(y = 0.75x + 3.25\):

• At \(x=2\), \(y_{pred}=4.75\) (actual \(y=2, 6\); residuals \(-2.75, 1.25\))
• At \(x=5\), \(y_{pred}=7.0\) (actual \(y=5\); residual \(-2.0\))
• At \(x=8\), \(y_{pred}=9.25\) (actual \(y=10\); residual \(0.75\))

For \(y = 0.75x + 1.5\):

• At \(x=2\), \(y_{pred}=3.0\) (actual \(y=2, 6\); residuals \(-1.0, 3.0\))
• At \(x=5\), \(y_{pred}=5.25\) (actual \(y=5\); residual \(-0.25\))
• At \(x=8\), \(y_{pred}=7.5\) (actual \(y=10\); residual \(2.5\))

The line \(y = 0.75x + 1.5\) passing through \((2, 3)\) and \((6, 6)\) splits the data points more evenly with a better balance of points above and below the line across the entire domain.

Answer:

• (A) (3, 5) and (8, 7)
• (B) (2, 3) and (6, 6) (Correct answer)
• (C) (1, 4) and (9, 10)
• (D) (2, 2) and (9, 10)
